MS3476W16-29S CONNECTOR
On hand in Los Angeles: 80 pcs. Factory new, traceable, C of C included. Request a quote for same-day pickup or shipment.
MS3476W16-29S – MIL-DTL-26482 Series 2 straight plug.
- Specification: MIL-DTL-26482 Series 2, MS3476
- Connector type: Straight plug
- Class / finish: Class W, aluminum, olive-drab cadmium over nickel, -55 °C to +175 °C
- Shell size: 16
- Insert arrangement: 16-29
- Contact type: Socket (S), rear-release crimp
Factory-new, stocked in Los Angeles. Quotes answered within one business day. Call (310) 845-1555.
Description
MS3476W16-29S – MIL-DTL-26482 Series 2 straight plug
Newcastle Industries stocks the MS3476W16-29S connector from Amphenol Aerospace in our Los Angeles warehouse. Every unit is factory new, and we supply the manufacturer’s certificate of conformance and lot traceability with your order.
Specifications
| Specification | MIL-DTL-26482 Series 2, MS3476 |
|---|---|
| Connector type | Straight plug |
| Class / finish | Class W, aluminum, olive-drab cadmium over nickel, -55 °C to +175 °C |
| Shell size | 16 |
| Insert arrangement | 16-29 |
| Contact type | Socket (S), rear-release crimp |
| Mates with | Any MIL-DTL-26482 Series 2 (or Series 1) connector of shell size 16, insert 29, opposite contacts |
| Accessories | M85049/52 (straight) or M85049/51 (90°) strain relief size 16; MS3180 / MS3181 covers |
| Coupling | Three-point bayonet, quick-disconnect |
| Contact termination | Rear-release crimp, wire 24 to 12 AWG |
| Contact rating | 7.5 A per size 20 contact; 13 A size 16; 23 A size 12 |
| Service rating | I = 600 V RMS, II = 1,000 V RMS at sea level |
| Mating cycles | 500 (250 for MS3475 RFI plug) |
| Manufacturer | Amphenol Aerospace |
| Condition | Factory new, unused, original manufacturer packaging |
| Traceability | Manufacturer certificate of conformance available on request |
| Ships from | Los Angeles, California (same-day on stock items) |
About MIL-DTL-26482 Series 2
MIL-DTL-26482 Series 2 connectors keep the bayonet coupling and insert arrangements of Series 1 but move to rear-release crimp contacts and environmental sealing. They are standard on military aircraft wiring, missiles, ground radar and commercial aerospace test systems.
How to order MS3476W16-29S
Send us the quantity and your required date through the request-a-quote form, or call (310) 845-1555 Monday to Friday, 9 am to 5 pm Pacific. Quotes are answered within one business day. We ship worldwide via UPS, FedEx and freight forwarders, and we can ship on your carrier account.
Need a different shell size, insert arrangement, contact gender or finish? We stock thousands of related part numbers. Tell us the mating connector or the drawing callout and we will cross-reference it.
