MS3456W16S1P – MIL-DTL-5015 Series III crimp straight plug
Newcastle Industries stocks the MS3456W16S1P connector from Amphenol Aerospace in our Los Angeles warehouse. Every unit is factory new, and we supply the manufacturer’s certificate of conformance and lot traceability with your order.
Specifications
| Specification | MIL-DTL-5015 Series III (threaded, rear-release crimp), MS3456 |
|---|---|
| Connector type | Straight plug |
| Class / finish | Class W, aluminum, olive-drab cadmium, -55 °C to +175 °C |
| Shell size | 16S |
| Insert arrangement | 16S-1 (MIL-STD-1651), 7 contacts, size 16 |
| Contact type | Pin (P), rear-release crimp (tools M22520/1-01, /2-01, /7-01) |
| Mates with | MS3100-series solder, MS3400-series and MS3450-series crimp, and MIL-DTL-83723 Series II connectors of shell size 16S, insert 1 |
| Coupling | Threaded, environmentally sealed |
| Contact termination | Rear-release crimp, sizes 20 to 0 |
| Manufacturer | Amphenol Aerospace |
| Condition | Factory new, unused, original manufacturer packaging |
| Traceability | Manufacturer certificate of conformance available on request |
| Ships from | Los Angeles, California (same-day on stock items) |
About MIL-DTL-5015 (MS3450 series)
The MS3450 series is the threaded, environmentally sealed, rear-release crimp version of MIL-DTL-5015 (Series III), designed to replace the solder-contact MS3100 series while intermating with it. It keeps the 5015 power ratings (13 A size 16, 23 A size 12, 46 A size 8, 80 A size 4) and adds crimp contacts that can be removed with standard M81969 tools. It also intermates with MIL-DTL-83723 Series II.
How to order MS3456W16S1P
Send us the quantity and your required date through the request-a-quote form, or call (310) 845-1555 Monday to Friday, 9 am to 5 pm Pacific. Quotes are answered within one business day. We ship worldwide via UPS, FedEx and freight forwarders, and we can ship on your carrier account.
Need a different shell size, insert arrangement, contact gender or finish? We stock thousands of related part numbers. Tell us the mating connector or the drawing callout and we will cross-reference it.
Request a Quote for MS3456W16S1P
